MTP Connector Compliance |
IEC 61754-7, TIA 604-5, RoHS |
|
Base-8 |
96 Fibers |
|
Base-12 |
144 Fibers |
|
Base-24 |
288 Fibers |
|
Cable Diameter |
10.3mm |
|
Subunit Diameter |
3.0mm |
|
Operating Temperature |
-10°C to +70°C |
|
Flammability |
UL94 V-0 |
|
Durability |
> 100 mating cycles |
|
Transmission with Applied Tensile Load |
50 Newton |
|
Insertion Loss: IEC 61300-3-4-MB |
Average: 0,10dB, Max: 0,35dB |
|
Return Loss: IEC 61300-3-6-MB |
Singlemode: ≥ 60dB |
