LC Connector Compliance

IEC 61754-20, TIA 604-10-A, RoHS

SC Connector Compliance

IEC 61754-4, TIA 604-3, RoHS

FC Connector Compliance

IEC 61754–13, TIA 604–4–A, RoHS

ST Connector Compliance

IEC 61754–2, TIA 604–2, RoHS

E2000 Connector Compliance

IEC 61754 - 15, TIA 604 - 16, RoHS

Alignment Technology

Full ceramic ferrule (Zirconia ZrO2)

Operating Temperature

-40°C to +85°C

Flammability

UL94 V-0

Durability

> 1000 mating cycles

Transmission with Applied

Tensile Load

GR-326 CORE 4.4.3.5

Insertion Loss: IEC 61300-3-4-MB

Singlemode: ≤ 0.30dB

Return Loss: IEC 61300-3-6-MB

Singlemode UPC: ≥ 50dB

Singlemode APC: ≥ 60dB

Connector End Face Geometry

IEC 61755-3
