• Sheet steel housing ,completely pre-assembled, self ventilated,
• Surface finish: powder painted in RAL 7035 – light grey (other colors on request),
• Protection IP20 in accordance with PN 92/E-08106/EN 60529/IEC 529. (does not apply to brush cable entries),
• Indoor use,
• Integrated plinth (100 mm height) with one cable entry on the back side (250 x 70 mm),
• In the roof and base of cabinet 2 x 4 U blind plates (pre-punched openning) for fan units (possible configurations 1 or 2 x 2 fan units, 1 x 4 fan units, 1 x 6 fan units),
• Cabinet made of – 1,5 mm thick sheet steel on 4 x leveling feet M10
• Optionally:
  • – cabinet wheel kit – 11190143 (maximum load capacity 100 kg)
  • – heavy duty castor set – (maximum load capacity 150 kg) for cabinets 600 width – 11190160, and for 800 width – 11190180.

Specifications may change without notice. Display Product Photos Shown are samples for viewing, not actual products.

• Five cables let in entry optionally either from roof or base, either through top or bottom of the rear side of cabinet and one in the plinth, pre-punched opening. (Dimensions: 250 x 70 mm),
• Front door: with window made of safety glass (optionally: full steel), opening angle 180 degrees, with single point lock. Door stop possible on the right and left side.
• Cabinet rear panel – 1,5 mm thick sheet steel, removable, fixed by six screws from outside,
• Cabinet side panels – 1,5 mm thick sheet steel, not removable,
• One set of mounting rails (AlZn coated) each arranged at the front on the inside,
• New profiles fixing system efficently increases maximum load capacity of the cabinets and faciltate of cables management. Profile rails with 25 mm hole spacing arranged horizontally of the top and the bottom of the cabinet, for fixing and depth adjustment of the profile rails,
• Minimum distance from the front door and front profile rails – 48 mm,
• Maximum spacing between front and rear profile rails:
  • – Cabinet depth 600 mm – max 472 mm
  • – Cabinet depth 800 mm – max 672 mm
• Internal cabinet sections fully earthed (grounding cords lenght; 30cm, 6mm²) to the cabinet bottom,
• Wide range of supplementary accesories:plinths, shelves, fan units, light units, power distribution units, blanking covers, cable management accessories etc
• Delivery in secure transport carton and stretch packaging on disposable pallet.
